A 6-week live program that trains you to design, implement, and verify a RISC-V processor from the ground up — using only open-source tools.

Apply for RISE → View curriculum
6 weeks
Duration
Live
Online sessions
Fully
Funded seats available
100%
Open-source tools
Why RISE

India's chip ambitions
need RISC-V engineers.

RISC-V is the open ISA at the center of India's semiconductor push — from national initiatives to global chip startups. RISE closes the training gap.

ISA
Architecture-first, not tool-first
You learn why RISC-V works the way it does — instruction encoding, the extension model, privilege levels — before touching RTL.
RTL
Real designs, not toy examples
You write and simulate a pipelined processor. Every lab adds to a core that runs real software by week six.
SoC
System-level perspective
Buses, memory maps, interrupts — you see how a processor core lives inside a complete SoC, not just in isolation.
OSS
Entirely open-source toolchain
Verilator, Spike, QEMU, GTKWave — everything free. No licenses, no institutional access required.
6
Live training weeks
∞
No ISA royalties
6+
Hands-on lab modules
1
Capstone RISC-V core
Tools you'll use
VerilatorSpike ISSQEMUGTKWaveriscv-gccSystemVerilogriscv-testsOpenOCD
What you'll learn

Six weeks. Built to stack.

Each module builds directly on the last — from ISA fundamentals to a verified pipelined core running real software.

Week One
Logic Design & Verilog Foundations
  • Mux, demux, logic design
  • Adders, multipliers, flip-flops
  • Logic design modules, gates, mux, demux, FIFO
  • Verilog: registers, adder, multiplier, verification
Theory + Lab
Week Two
ISA & RV32I Processor Basics
  • ISA basics and simple RISC processor design
  • RISC-V instruction set and RV32I
  • Control logic and simple RISC processor design part 2
  • Instruction execution flow and datapath design
Hands-on RTL
Week Three
Pipelining & Hazards
  • Pipelining: interlock, bypass, structural, data, and control hazards
  • Execution and interrupts, branch delay slot
  • Complex in-order pipelines: CDC6600 and MIPS R4000
Core RTL
Week Four
Memory Hierarchy
  • Memories and caches: direct-mapped and set-associative
  • Replacement policy, write policy, cache performance, write buffer
  • Multi-level caches and address translation
  • Base-and-bound, paged memory, TLBs, page faults, virtual address caches
System Design
Week Five
Out-of-Order Execution
  • Scoreboarding and complex in-order pipeline concepts
  • Tomasulo's architecture, out-of-order issue, and register renaming
  • Unified physical register file and in-order commit
  • Branch prediction: BHT and Branch Target Buffer
Advanced Architecture
Week Six
Parallelism & Capstone
  • VLIW processors, loop unrolling, software pipelining
  • Multithreading, vector processors, strip mining, chaining, reduction
  • Snoopy caches, MSI/MESI, directory-based protocols
  • Synchronization, TSO, locks, test-and-set, LR/SC
  • Capstone: your own RV32I core
Capstone
Financial support

Talent, not tuition,
earns a seat here.

A meaningful share of every cohort is fully funded. We evaluate on motivation and aptitude — not institution or income.

Scholarship applications open

Up to 100% fee waiver for the right candidates

Apply alongside your registration. Short answers, no essays. We review on a rolling basis — applying early gives you an advantage.

Merit Scholarship — Grade 1
Highest merit band
100% scholarship
Merit Scholarship — Grade 2
Strong merit band
75% fee waiver
Merit Scholarship — Grade 3
Solid merit band
50% fee waiver
Merit Scholarship — Grade 4
Entry merit band
25% fee waiver
What we look for
Genuine interest in chip design or computer architecture
Clear answer to: what will you build after this?
Commitment to attending live sessions
For need-based: honest financial context
How to apply
The scholarship form is embedded inside registration. After approval, send the matching Razorpay payment link manually for the selected scholarship tier.
No institution required
You don't need to be from a specific college or company. Independent learners, working professionals, and self-taught engineers are all eligible.
Who should apply

Built for engineers
at every stage.

📘
Any-year undergrads
First-year to final-year students from ECE, EEE, CS, or Physics who want a fast start in RTL, processor design, and computer architecture.
🧠
Postgrad researchers
M.Tech and PhD students in computer architecture or SoC design looking to go deeper.
🔧
Working engineers
RTL, verification, or embedded software professionals moving into RISC-V chip design.
⚡
Chip startup builders
Early-stage founders and engineers building custom silicon who need a rigorous foundation fast.
After RISE

What you walk
away with

✓
Learn to design a single-cycle RV32I compliant processor from scratch in Verilog/SystemVerilog.
✓
Deep memory hierarchy knowledge — caches, replacement & write policies, virtual memory, page tables, and TLBs.
✓
Out-of-order execution mastery — scoreboarding, Tomasulo's algorithm, register renaming, and branch prediction (BHT/BTB).
✓
Parallel architecture fundamentals — VLIW, vector processors, multithreading, cache coherence (MSI/MESI), and synchronization primitives.
✓
Open-source EDA fluency — Verilator, Spike, QEMU, GTKWave, and the riscv-tests compliance suite.
✓
RISE certificate of completion and alumni network access — fellow RISE engineers, future cohort updates, and career resources.
RISE Cohort 2
Program at a glance
Full nameRISC-V for Indian Semiconductor Education
Duration6 weeks (1.5 months)
FormatLive online + recordings
Sessions4–5× per week, evenings
PrerequisitesNone · just honest interest
Tools100% open-source
ScholarshipAvailable · apply in form
SeatsLimited · rolling basis
Apply for RISE Cohort 2→
No payment now · commitment-free
Key dates & eligibility

What happens next

Right now
Interest & scholarship applications open
Register and complete the scholarship section if applicable. Rolling review — earlier applications have an advantage.
Within 15 days of applying
Scholarship decisions communicated
All scholarship applicants are notified within 15 days of applying. Merit and need-based awards are announced together.
Before cohort start
Onboarding and tool setup
Confirmed participants receive pre-reading, Linux/WSL setup guides, and cohort workspace access.
TBA · Cohort 2
RISE begins
Six weeks of live sessions, weekly labs, and office hours — ending with your capstone RISC-V core.
Eligibility checklist
✓Any-year undergrads or college students in ECE, EEE, CS, or Physics
✓M.Tech / M.Sc / PhD students in relevant fields
✓Working professionals in hardware or embedded software
✓No prior RISC-V or processor-design experience required
✓Honest interest in chip design, architecture, and RTL
✓Can commit 4–5 evenings per week for 6 weeks
✓Linux machine or Windows with WSL
No prior experience is required. If you are curious about how processors work and want to learn, you are eligible to apply.
Common questions

FAQ

What background do I need?+
No prior RISC-V or processor-design experience is required. Honest interest and a willingness to learn are enough to start.
How many hours per week?+
Expect 8–12 hours per week — roughly 3–4 hours of live sessions and 5–8 hours of labs. Designed to fit alongside a college schedule or part-time work.
Are sessions recorded?+
Yes — all live sessions are recorded and available for the cohort duration. Attending live is encouraged because the Q&A and peer discussions are where a lot of learning happens.
How do I apply for scholarship?+
The scholarship form is embedded in the registration flow — no separate portal. A few short questions. Decisions within 15 days of applying, rolling basis.
What tools will we use?+
The entire toolchain is open-source: Verilator for RTL simulation, GTKWave for waveforms, Spike as the RISC-V ISA reference simulator, QEMU for system emulation, and the RISC-V GCC toolchain. All runs on Linux or Windows WSL.
Is there a certificate?+
Yes. Participants who complete sessions, labs, and the capstone receive a RISE certificate from Semiconductor School. The capstone RTL project is the more valuable portfolio piece.
Will there be more cohorts?+
Yes — RISE is planned as a quarterly program. Registering your interest now keeps you informed even if Cohort 2 fills before you apply.
Is this right for working professionals?+
Absolutely. Evening sessions and weekend lab time fit around day jobs. Scholarship tiers are also open to professionals looking to upskill or transition into chip design.
